Clear span tent

A-Frame Clear Span Tent is our standard and most popular design in the past years. The width varies from 3m to 60m, length has no limitation. Length can be any times of 3m or 5m modular. There is no pole inside the tent, which enables you to make maximum use of the space inside. Most popular size are 6x12m, 9x15m, 10x20m, 12x30m, 15x40m, 20x30m, 20x50m, 25x60m, 30x60m, 30x100m, 40x100m, 50x100m Ect. It is widely used as a wedding tent, party tent, marquee.  Accessories available are lining & curtain, glass wall, glass door, ABS panel wall, Cassette wooden flooring system, ground anchor.

Category:
Tent Item no.Width (m)Truss Distance (m)Leg Height (m)Ridge Height (m)Truss Profile Size (mm)Roof PitchWind Load (km/h)
AK-6/25006m3m2.5m/3 m3.7m/4.2m84X48 mm22°100
AK-9/25009m3m2.5m/3 m4.2m/4.7m100X48 mm22°100
AK-10/250010m3m2.5mm/3 m4.5m/5m100X48 mm22°100
AK-10/300010m5m2.6m/3m/4 m4.26m/4.66m/5.66 m120X68 mm
110X110 mm
18°100
AK-12/300012m5m2.6m/3m/4 m4.58m/4.98m/5.98m120X68 mm
110X110 mm
18°100
AK-15/300015m5m3m/3.5m/4m5.49m/5.99m/6.49m
150X110mm18°100
AK-20/4000
20m
5m4m/5m/6m

7.31m/8.31m/9.31m
200X110mm
18°100
AK-20/4000
20m
5m3.4m/4m/5.4m
6.49m/7.09m/8.49m
200X120mm
18°120
AK-25/4000
25m5m4m/5m/6m
8.12m/9.12m/10.12m
200X110mm
18°120
AK-25/4000
25m5m3.4m/4m/5.4m
7.27m/7.87m/9.27m
200X120mm
18°120
AK-30/4000
30m5m4m/5m/6m
9m/10m/11m
250X110mm
18°120
AK-30/400030m5m3.4m/4m/5.4m

8.27m8.87m/10.27m
250X120mm
18°120
AK-40/4000
40m
5m3.4m/4m/5.4m
9.94m/10.54m/11.94m
300X120mm
18°120
AK-50/4000
50m
5m3.4m/4m/5.4m
11.57m/12.17m/13.57m
300X120mm
18°120
AK-60/4000
60m5m4m/5.4
13.94m/15.34m
420X120mm
18°120
item details
Frame materialHard Pressed Extruded Aluminum Alloy 6061/T6(15HW)
Side Wall CoverPVC walls,glass wall,ABS wall,sandwich pannel ect
Roof Cover850g/s double PVC-coated polyester textile
ConnectorsHot-DIP Galvanized/strong hot-dip galvanized steel.
Service LifeMore than 15 years
Snow load75kg/sqm (snow can't stay if use big degree roof pitch design).
Doorsdouble-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter
